V80 Part List

V80 Part List

062K 24942(SSC) ROS Assembly (Y/ M) (with Item 10) (REP 2.1.1, REP 99.1.1) (ADJ 18.1.7)
062K 24942(SSC) ROS Assembly (C/ K) (with Item 10) (REP 2.1.2, REP 99.1.1) (ADJ 18.1.7)
952K 15570Flat Cable (Y, M)
952K 15580Flat Cable (C, K)
130K 88740REGICON Temp Sensor (REP 2.1.3)
801E 27652Right ROS Cover
801E 27641Left ROS Cover
007K 19370Main Motor Assembly (REP 3.1.1)
869E 00491Flywheel (Y, M, C, K) (REP 3.1.2)
054E 51680Deve. Cooling Fan Duct
127K 70590(SCC) Deve. Cooling Fan (M) (REP 99.1.1)
127K 70590(SCC) Deve. Cooling Fan (C) (REP 99.1.1)
007K 19360Drum/Deve. Motor Assembly (Item 2-6) (Y) (REP 3.2.1)
007K 19360Drum/Deve. Motor Assembly (Item 2-6) (M, C) (REP 3.2.2)
007K 19360Drum/Deve. Motor Assembly (Item 2-6) (K) (REP 3.2.3)
127K 61140(SCC) Deve. Motor (REP 99.1.1)
127K 70020(SCC) Drum Motor (REP 3.2.4, REP 99.1.1)
848E 99611Tonner Dispenser Inner Cover (REP 5.1.1)
CT202299Toner Cartridge (Y) (FX) (TSC)
CT202303Toner Cartridge (Y) (FX) (MSC)
CT202295Toner Cartridge (Y) (APO/GCO)
CT202298Toner Cartridge (M) (FX) (TSC)
CT202302Toner Cartridge (M) (FX) (MSC)
CT202294Toner Cartridge (M) (APO/GCO)
CT202297Toner Cartridge (C) (FX) (TSC)
CT202301Toner Cartridge (C) (FX) (MSC)
CT202293Toner Cartridge (C) (APO/GCO)
CT202296Toner Cartridge (K2) (FX) (TSC)
CT202300Toner Cartridge (K2) (FX) (MSC)
CT202292Toner Cartridge (K2) (APO/GCO)
CT202296Toner Cartridge (K1) (FX) (TSC)
CT202300Toner Cartridge (K1) (FX) (MSC)
CT202292Toner Cartridge (K1) (APO/GCO)
848K 79411Drum/Deve. Cover
010K 92082Plunger Assembly
848K 73540Developer Housing (Y) (REP 5.2.1) (ADJ 18.1.16)
848K 73540Developer Housing (M) (REP 5.2.1) (ADJ 18.1.16)
848K 73540Developer Housing (C) (REP 5.2.1) (ADJ 18.1.16)
848K 73540Developer Housing (K) (REP 5.2.1) (ADJ 18.1.16)
676K 33640Developer (Y) (REP 5.2.2) (ADJ 18.1.16)
676K 33630Developer (M) (REP 5.2.2) (ADJ 18.1.16)
676K 33620Developer (C) (REP 5.2.2) (ADJ 18.1.16)
676K 33610Developer (K) (REP 5.2.2) (ADJ 18.1.16)
049K 21100Connector Bracket Assembly (Y) (REP 5.3.1)
049K 21100Connector Bracket Assembly (M) (REP 5.3.2)
049K 21100Connector Bracket Assembly (C) (REP 5.3.2)
049K 21100Connector Bracket Assembly (K) (REP 5.3.2)
952K 10520Wire Harness (Bias-C/K)
952K 10540Wire Harness (Bias-Y/M)
094K 93622Toner Dispenser (Y) (REP 5.4.1)
094K 93632Toner Dispenser (M) (REP 5.4.2)
094K 93642Toner Dispenser (C) (REP 5.4.2)
094K 93612Toner Dispenser (K1/K2) (REP 5.4.2)
113K 83781Toner CRUM PWB (Y, M, C, K1, K2) (REP 5.4.3)
960K 01281Low Toner Sensor PWB (REP 5.4.4)
094K 93603Toner Dispenser Assembly (Y, M, C, K1/K2) (Item 1- 14) (REP 5.4.5)
604K 90303IBT Belt Unit Kit (Item 2, 3) (REP 6.1.1) (ADJ 18.1.7)
012K 97040Lock Link Assembly
042K 94710IBT Cleaner Assembly (PL 6.9) (REP 6.1.2)
062K 25840Conductor Assembly BUR
003K 93290Handle Assembly (Item 12-14)
803E 17661IBT Handle
848K 89580Handle Cover Assembly (Item 16, 17)
822E 00080Handle Cover
064K 94190IBT Belt (REP 6.2.1) (ADJ 18.1.7) (ADJ 18.1.17)
019E 859912nd Holder
848K 80530Back up Roll Housing Assembly (Item 6-9) (REP 6.2.2)
059K 86790Back up Roll Assembly (Item 7, 8)
059K 808811st BTR Roll (Y, M, C, K) (REP 6.3.1)
019K 15710BTR Holder Assembly (K) (Item 3, 4)
019K 15720BTR Holder Assembly (Y, M, C) (Item 6, 7)
005K 83890Encoder Disc
007K 98820IBT Drive Assembly (REP 6.3.2)
127K 70770(SCC) IBT Drive Motor (REP 99.1.1)
130K 89210(SCC) IBT Drive Encoder A (REP 99.1.1)
130K 89210(SCC) IBT Drive Encoder B (REP 99.1.1)
059K 81561IBT Drive Roll (REP 6.3.3)
807E 42610Idler Gear (20T)
807E 42262IBT Drive Gear (58T)
822E 00340IBT Encoder Cover
059K 80950Retract Roll Assembly
059K 81790Cleaner Roll Assembly
803E 17680IBT Slide Foot
803E 17670IBT Foot
059K 82661IBT Steering Roll (REP 6.5.1)
127K 70470(SCC) IBT Steering Motor (REP 6.5.2, REP 99.1.1)
127K 70460(SCC) 1ST BTR Contact/Retract Motor (REP 6.6.1, REP 99.1.1)
105E 19850(SCC) 1ST BTR HVPS (REP 99.1.1)
006K 94980Retract Shaft Assembly (REP 6.6.2)
952K 12530(SCC) IBT Wire Harness Assembly (Item 10-14) (REP 99.1.1)
050K 71530IBT Drawer Left Rail Assembly (REP 6.7.1)
050K 70990IBT Drawer Right Rail Assembly (REP 6.7.1)
801E 27760IBT Drawer Front Frame
848K 81181IBT Inner Cover
059K 868412nd BTR Assembly (Item 2, 3) (REP 6.8.1)
054E 52941Upper Inlet Chute
826E 63330Shoulder Screw
105E 11770(SCC) DTS HVPS S3 (REP 6.8.2, REP 99.1.1)
033K 98760IBT Blade Assembly (Item 3-6) (REP 6.9.1)
059K 81360V-TRA Assembly (PL 7.3) (REP 7.1.1)
127K 70810(SCC) Fusing Pressure Roll Fan Assembly (REP 7.1.4, REP 99.1.1)
869E 03150PR Handle Bracket
003K 89870BM Handle Bracket
126K 34411(SCC) Fusing Unit Kit (Item 9-13) (REP 99.1.1)
604K 90030Harness Kit (Type1/2)
007K 19450Fusing Unit Drive Assembly (Item 2-15)
127K 70800(SCC) Fusing Unit P/R Motor Assembly (REP 99.1.1)
127K 70990(SCC) P/R Latch Motor Assembly (REP 99.1.1)
807E 42920Input Gear
604K 87860V-TRA Belt Kit (Kit for 4 belts.) (REP 7.3.1)
899E 04910Spring
930W 00222Fusing Inlet V-TRA Sensor
146K 91030Belt Encoder Assembly
815E 86360Support Plate
126K 34850(SCC) Fusing Belt Unit (Item 7-9) (REP 7.4.1, REP 99.1.1)
899E 04890Baffle Spring
055K 39630Baffle Assembly
054E 53190Inlet Chute
019K 15350Finger Assembly (REP 7.4.2)
803E 18300Front Stopper
803E 17820Rear Stopper
059K 81320Presser Roll Assembly (REP 7.4.3)
042K 94660Cleaner Assembly (REP 7.4.4)
920W 01209Locking Clamp
920W 01212Locking Clamp
127K 70780(SCC) Fusing Belt Walk Motor (REP 99.1.1)
130K 79730Fusing Belt Position Sensor Assembly
913W 13410Connector
913W 13411Connector
913W 13412Connector
130K 79800(SCC) IRS Sensor 2 (Front) (REP 99.1.1)
130K 79800(SCC) IRS Sensor 1 (Rear) (REP 99.1.1)
007K 98681Fusing Gear Assembly (Item 4, 5)
054K 51060Exit Chute Assembly (Item 7-10)
930W 00222Fusing Unit Exit Sensor
059K 81490(SCC) Decurler Transport Assembly (PL 7.9) (REP 7.7.1, REP 99.1.1)
127K 70820(SCC) Decurler Fan (REP 7.7.2, REP 99.1.1)
127K 70860(SCC) V-TRA Motor Assembly (REP 7.7.3, REP 99.1.1)
920W 01209Locking Clamp
007K 19580Decurler Drive Assembly (Item 2, 3) (REP 7.8.1)
127K 58250(SCC) Decurler Pene Up Motor (REP 99.1.1)
913W 12124Connector
127K 70960(SCC) Decurler Pene Down Motor (REP 99.1.1)
049K 26060Bracket
130K 79680Xero. Environment Sensor (REP 8.1.2)
801K 16741Erase Lamp Rail (Y, M, C, K)
952K 14141Wire Harness
CT351054Drum Assembly (Y) (REP 8.2.2) (FX)
CT351050Drum Assembly (Y) (REP 8.2.2) (APO/GCO)
CT351054Drum Assembly (M) (REP 8.2.2) (FX)
CT351050Drum Assembly (M) (REP 8.2.2) (APO/GCO)
CT351054Drum Assembly (C) (REP 8.2.2) (FX)
CT351050Drum Assembly (C) (REP 8.2.2) (APO/GCO)
CT351054Drum Assembly (K) (REP 8.2.2) (FX)
CT351050Drum Assembly (K) (REP 8.2.2) (APO/GCO)
822E 03241Xero Add Cover
050K 72690Drum/Deve. Drawer Frame Assembly (Item 1, 8)
010K 92090Rear Plunger
032E 42090Front Drum Guide
032E 42102Rear Drum Guide
815K 14150Catch Plate
013K 83050Bearing Assembly
803E 18050Drawer Handle
003K 93270Drawer Handle Assembly (Item 9, 10)
130K 79514MOB/ADC Sensor Assembly (REP 8.3.1) (ADJ 18.1.7)
CWAA0554Waste Bottle (FX)
CWAA0663Waste Bottle (APO/GCO)
130K 77040Waste Bottle Full Sensor Assembly (REP 8.4.1)
848K 19490Tray Right Inner Cover (REP 8.4.2)
019K 15300CRUM Holder (Y, M, C, K) (REP 8.5.4)
052K 13510Collector Pipe Assembly (REP 8.5.1)
052K 13520Bottom Elbow Assembly (Item 4-8) (REP 8.5.2)
093K 26700Slant Funnel Assembly (REP 8.5.3)
113K 83781Drum CRUM PWB (Y, M, C, K) (REP 8.5.6)
114K 82660BCR Connector (Y, M, C, K) (REP 8.5.5)
952K 16181Wire Harness
059K 86750(SCC) Tray 1 Feeder (PL 10.7) (REP 10.1.1, REP 99.1.1)
059K 86750(SCC) Tray 2 Feeder (PL 10.7) (REP 10.1.1, REP 99.1.1)
059K 86750(SCC) Tray 3 Feeder (PL 10.7) (REP 10.1.1, REP 99.1.1)
059K 26480Takeaway Roll 1 (REP 10.3.1)
059K 26480Takeaway Roll 2 (REP 10.3.1)
059K 26480Takeaway Roll 3 (REP 10.3.1)
017K 96150Caster
059K 26562Tray 1 Feed Roll (REP 10.7.1)
059K 26562Tray 2 Feed Roll (REP 10.7.1)
059K 26562Tray 3 Feed Roll (REP 10.7.1)
059K 26572Tray 1 Nudger Roll (REP 10.7.1)
059K 26572Tray 2 Nudger Roll (REP 10.7.1)
059K 26572Tray 3 Nudger Roll (REP 10.7.1)
059K 26591Tray 1 Retard Roll (REP 10.7.1)
059K 26591Tray 2 Retard Roll (REP 10.7.1)
059K 26591Tray 3 Retard Roll (REP 10.7.1)
127K 71410(SCC) Tray 1 Feed Lift Motor (REP 99.1.1)
127K 71410(SCC) Tray 2 Feed Lift Motor (REP 99.1.1)
127K 71410(SCC) Tray 3 Feed Lift Motor (REP 99.1.1)
012K 97110Link Assembly
005K 84000Friction Clutch
121K 41750(SCC) Takeaway Clutch 1 (REP 10.12.1, REP 99.1.1)
121K 41750(SCC) Takeaway Clutch 2 (REP 10.12.1, REP 99.1.1)
121K 41750(SCC) Takeaway Clutch 3 (REP 10.12.2, REP 99.1.1)
059K 87970Inverter Transport Kit (Item 2-13)
059K 80550Swing Transport Assembly (PL 16.2, PL 16.3)
848E 98930Inverter Rear Cover
059K 80540Fix Transport Assembly (PL 16.4)
003K 93540Knob Kit (Item 2, 3)
055E 64410Guard
012K 96921Link Assembly
007K 19260(SCC) Invert In Gate Motor Assembly (Item 16-18) (REP 99.1.1)
899E 03730Pinch Spring
899E 03740Pinch Spring
930W 00212Invert In Sensor
127K 70260(SCC) Invert Motor (REP 99.1.1)
127K 70680(SCC) Invert N/R Motor (REP 99.1.1)
899E 03720Pinch Spring
003K 16000Latch Assembly
005E 24340Coupling
930W 00212Invert Path Sensor
054K 53280Inverter Chute Unit Kit (Item 1, 7-14)
